Valmet
Caterpillar
554
Forwarder
33 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight - 8wd | 42,108 lb |
|---|---|
| Operating Weight - 6wd | 37,038 lb |
| Fuel Capacity | 42.0 gal |
| Hydraulic System Fluid Capacity | 34.3 gal |
| Alternator Supplied Amperage | 100 A |
| Operating Voltage | 24 V |
| Front/Rear Tire Size - 8wd | Front & Rear :650/65x26.5 750/55x26.5 750/45x30.5 |
| Front/Rear Tire Size - 6wd | 700/70x34 Rear : 650/65x26.5 750/55x26.5 750/55x30.5 |
Engine
| Engine Model | 74 CTA Turbo w/ Commonrail.Tier 3 |
|---|---|
| Power | 204.0 hp |
| Torque | 742 lb-ft |
Hydraulic System
| Pump Type | Variable Piston Pump |
|---|---|
| Relief Valve Pressure | 3,400 psi |
| Flow Capacity | 90.0 gal/min |
Dimensions
| Ground Clearance | 28 in |
|---|---|
| Wheelbase | 66 in |
| Width Over Tires | 118 in |
| Length | 366 in |
| Length of Bunk Area | 196 in |
| Height to Top of crane | 150 in |
Transmission
| Max Speed | 15.5 mph |
|---|---|
| Transmission Type | Hydrostatic |
Bunk
| Load Area | 1.71 yd³ |
|---|---|
| Load Weight - 8wd | 39,680 lb |
| Load Weight - 6wd | 39,680 lb |
Crane
| Max Reach | 295 in |
|---|---|
| Gross Lift Torque | 114,298 lb-ft |
| Crane Type | CRF 14 |
| Gross Slew Torque | 30,460 lb-ft |
