Valmet
Caterpillar
570
Processor
18 specifications
1 / 5
Image 1 of 5
Specifications
17 data points
Operating Specifications
| Operating Weight | 33,290 lb |
|---|---|
| Max Speed | 15.6 mph |
| Fuel Capacity | 97.8 gal |
| Operating Voltage | 24 V |
| Transmission Type | Hydrostatic mechanical |
Engine
| Engine Model | 66 CTA Tier 3 |
|---|---|
| Displacement | 403 in³ |
| Net Power | 190.0 hp |
Dimensions
| Height - Top of Cab | 154 in |
|---|---|
| Wheelbase | 131 in |
| Overall Width | 115 in |
| Shipping Length - non tilt | 248 in |
Boom
| Max Reach w/ Head | 433 in |
|---|
Drive System
| Tire Size - front | 600/65x34 |
|---|---|
| Tire Size - rear | 700/55x34 |
| Number of Axels | 2 |
| Drive Configuration | 4 wheeldrive |
