Volvo
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 10,140 lb |
|---|---|
| Tire Size | front 13-28 10ply rear 7.50-18 10ply |
| Static Tipping Weight | 3,970 lb |
| Turning Radius | 166 in |
Engine
| Power Measured @ | 2,250 rpm |
|---|---|
| Gross Power | 47.0 hp |
| Number of Cylinders | 3 |
| Torque Measured @ | 1,350 rpm |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 96 in |
| Wheelbase | 83 in |
| Width Over Tires | 81 in |
| Reach at Max Lift and Dump | 36 in |
| Length with Bucket on Ground | 209 in |
| Hinge Pin - Max Height | 138 in |
Transmission
| Max Speed - Forward | 17.2 mph |
|---|---|
| Max Speed - Reverse | 17.2 mph |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 6 |
Bucket
| Bucket Capacity - heaped | 2.39 yd³ |
|---|---|
| Bucket Capacity - struck | 0.71 yd³ |
| Dump Clearance at Max Raise | 110 in |
