SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
60 data points
Operating Specifications
| Operating Weight | 66,390 lb |
|---|---|
| Fuel Capacity | 124.2 gal |
| Hydraulic Pump Flow Capacity | 132.0 gal/min |
| Hydraulic System Fluid Capacity | 105.7 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 8.0 gal |
| Cooling System Fluid Capacity | 9.6 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 3.0 gal |
| Alternator Supplied Amperage | 80 A |
Engine
| Engine Model | D7E EAE3 |
|---|---|
| Displacement | 436 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 205.0 hp |
| Net Power | 192.0 hp |
| Aspiration | Turbocharged with Intercooler |
| Torque Measured @ | 1,350 rpm |
| Max Torque | 712 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 120 in |
| Length of Track on Ground | 158 in |
| Tail Swing Radius | 119 in |
| Width to Outside of Tracks | 134 in |
| Removal Counterweight Clearance | 46 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.2 mph |
| Shoe Size | 32 in |
| Number of Shoes per Side | 50 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 51,820 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 270 in |
|---|---|
| Max Reach Along Ground | 393 in |
| Max Loading Height | 264 in |
| Max Vertical Wall Digging Depth | 215 in |
| Max Cutting Height | 379 in |
| Shipping Length of Unit | 414 in |
| Shipping Height of Unit | 135 in |
Bucket
| Reference Bucket Capacity | 2.00 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 289 in |
|---|---|
| Max Vertical Wall Digging Depth | 245 in |
| Max Cutting Height | 396 in |
| Max Loading Height | 278 in |
| Max Reach Along Ground | 414 in |
| Shipping Length of Unit | 410 in |
| Shipping Height of Unit | 130 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 315 in |
|---|---|
| Max Cutting Height | 407 in |
| Max Loading Height | 289 in |
| Max Vertical Wall Digging Depth | 260 in |
| Max Reach Along Ground | 438 in |
| Shipping Length of Unit | 411 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 582 in |
|---|---|
| Max Cutting Height | 588 in |
| Max Reach Along Ground | 728 in |
| Max Loading Height | 496 in |
| Max Vertical Wall Dig Depth | 533 in |
| Shipping Length of Unit | 576 in |
