SK350LC-10 H&W
Excavator
35 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 66,200 lb |
|---|---|
| Fuel Capacity | 124.2 gal |
| Hydraulic System Fluid Capacity | 51.6 gal |
| Engine Oil Capacity | 8.5 gal |
| Cooling System Fluid Capacity | 10.9 gal |
Engine
| Engine Model | D7 |
|---|---|
| Displacement | 433 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 231.0 hp |
| Net Power | 220.0 hp |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 122 in |
| Length of Track on Ground | 192 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 43 in |
Undercarriage
| Number of Track Rollers per Side | 2 |
|---|---|
| Max Travel Speed | 3.4 mph |
| Number of Shoes per Side | 50 |
| Number of Carrier Rollers per Side | 9 |
| Drawbar Pull | 55,528 lb |
