Volvo
New Holland
E200SR
Excavator
44 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
63 data points
Operating Specifications
| Operating Weight | 37,831 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic Pump Flow Capacity | 12.5 gal/min |
| Hydraulic System Fluid Capacity | 68.7 gal |
| Hydraulic System Relief Valve Pressure | 4,641 psi |
| Engine Oil Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
| Hydraulic Pump Type | axial piston |
| Tire Size | 10.00-20 |
| Oscillating Axle Angle | 18 ° |
Engine
| Engine Model | D6D EJE2 |
|---|---|
| Displacement | 348 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 148.0 hp |
| Net Power | 138.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Net Torque | 439 lb-ft |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 103 in |
| Overall Width | 8 in |
| Tail Swing Radius | 79 in |
| Overall Width - Outriggers Down | 155 in |
Transmission
| Max Travel Speed | 21.8 mph |
|---|---|
| Transmission Type | powershift |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 0.99 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.10 yd³ |
| Minimum Bucket Capacity | 0.30 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 217 in |
|---|---|
| Max Cutting Height | 355 in |
| Max Reach Along Ground | 347 in |
| Max Loading Height | 245 in |
| Shipping Length of Unit | 324 in |
| Shipping Height of Unit | 125 in |
| Max Vertical Wall Dig Depth | 181 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 221 in |
|---|---|
| Max Cutting Height | 359 in |
| Max Reach Along Ground | 350 in |
| Max Loading Height | 248 in |
| Shipping Height of Unit | 128 in |
| Shipping Length of Unit | 323 in |
| Max Vertical Wall Dig Depth | 186 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 226 in |
|---|---|
| Max Cutting Height | 383 in |
| Max Reach Along Ground | 350 in |
| Max Loading Height | 284 in |
| Shipping Height of Unit | 244 in |
| Shipping Length of Unit | 328 in |
| Max Vertical Wall Dig Depth | 190 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 229 in |
|---|---|
| Max Cutting Height | 386 in |
| Max Reach Along Ground | 355 in |
| Max Loading Height | 288 in |
| Shipping Height of Unit | 244 in |
| Shipping Length of Unit | 121 in |
| Max Vertical Wall Dig Depth | 193 in |
