Volvo
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
73 data points
Operating Specifications
| Operating Weight | 35,715 lb |
|---|
Engine
| Engine Model | D6J |
|---|---|
| Displacement | 348 in³ |
| Gross Power | 154.0 hp |
| Number of Cylinders | 6 |
| Stroke | 5 in |
| Bore | 4 in |
| Max Power | — |
| Net Torque | 528 lb-ft |
Hydraulic System
| Implement | 5,439 psi |
|---|---|
| Main pump- low noise axial piston pump-MAX Flow | 72.7 gal/min |
| Pilot circuit | 508 psi |
| Maximum flow -Servo pump, low noise gear pump | 4.0 gal/min |
| Steering pump | 9.6 gal/min |
Dimensions
| Height - Top of Cab | 125 in |
|---|---|
| Wheelbase | 103 in |
| Overall Width | 108 in |
| Tail Swing Radius | 85 in |
| Counterweight Clearance | 50 in |
Fluid Capacities
| Fuel Tank | 66.1 gal |
|---|---|
| Engine Oil | 6.7 gal |
| Hydraulic Tank | 32.5 gal |
| Transmission | 0.7 gal |
| Engine coolant | 8.8 gal |
| Final Drive | 2.7 gal |
| Front axle | 153 in³ |
| Hydraulic tank - Total system | 66.1 gal |
| Rear Axle | 0.9 gal |
Boom/Stick Excavator Option 1
| Max Reach Along Ground | 343 in |
|---|---|
| Max Vertical Wall Digging Depth | 170 in |
| Max Cutting Height | 349 in |
| Max Digging Reach | 340 in |
| Max.Dumping Height | 233 in |
| Max Digging Reach on Ground | 331 in |
| Boom/Stick Option (HEX) 1 | MoonBoom 50 m(Ftin-165)Arm 2.0mm(Ftin-67) |
| Min - front slew radius | 125 in |
General Specifications
| Operating Weight lbs (kg) | 35,715 (16,200) Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 18.5 (5.7) Starting 2025 Model Year |
| Digging Reach ft. (m) | 30.2 (9.2) Starting 2025 Model Year |
| Engine hp (kW) | 154 (115) Starting 2025 Model Year |
Boom/Stick Excavator Option 2
| Max Digging Depth | 221 in |
|---|---|
| Max Vertical Wall Digging Depth | 189 in |
| Max Cutting Height | 359 in |
| Max Digging Reach | 355 in |
| Max.Dumping Height | 243 in |
| Max Digging Reach on Ground | 348 in |
| Boom/Stick Option (HEX) 2 | MoonBoom 50 m(Ftin-165)Arm 2.45mm(Ftin-80) |
| Min - front slew radius | 125 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 226 in |
|---|---|
| Max Cutting Height | 362 in |
| Max Vertical Wall Digging Depth | 194 in |
| Max.Dumping Height | 246 in |
| Max Digging Reach on Ground | 353 in |
| Boom/Stick Option (HEX) 3 | MoonBoom 50 m(Ftin-165)Arm 2.6mm(Ftin-86)) |
| Max Digging Reach | 361 in |
| Min - front slew radius | 125 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 246 in |
|---|---|
| Max Cutting Height | 373 in |
| Max Vertical Wall Dig Depth | 214 in |
| Max Digging Reach | 379 in |
| Max.Dumping Height | 257 in |
| Boom/Stick Option (HEX) 4 | MoonBoom 50 m(Ftin-165)Arm 3.1m(Ftin-102) |
| Min - front slew radius | 126 in |
| Max Digging Reach on Ground | 373 in |
Electrical System
| Batteries | 2 X12 volts |
|---|---|
| Alternator | — |
| Voltage | 24 V |
| Battery capacity | — |
| Alternator rating | 3360 W |
Speeds
| creep | 2.5 mph |
|---|---|
| Min turning radius | 288 in |
| speed -off road | 5.4 mph |
| speed -on road | 21.7 mph |
