Volvo
Venieri
363F
Wheel Loader
22 specifications
Volvo
L50D
- Operating Weight
- 18,916 lb
- Bucket Capacity - heaped
- 1.60 yd³
- Gross Power
- 101.5 hp
- Net Power
- 101.0 hp
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Operating Weight | 18,916 lb |
|---|---|
| Fuel Capacity | 39.7 gal |
| Tire Size | 17.5R25 |
| Hydraulic System Fluid Capacity | 17.2 gal |
| Static Tipping Weight | 13,228 lb |
| Operating Voltage | 24 V |
| Turning Radius | 210 in |
| Engine Oil Fluid Capacity | 3.0 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 60 A |
| Front Axle/Diff Fluid Capacity | 5.9 gal |
| Rear Axle/Diff Fluid Capacity | 5.9 gal |
| Cooling System Fluid Capacity | 7.2 gal |
| Transmission Fluid Capacity | 1.9 gal |
Engine
| Engine Model | TD 40 GJE |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 101.5 hp |
| Net Power | 101.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 31.8 gal/min |
|---|---|
| Raise Time | 5.4 s |
| Lower Time | 3.0 s |
| Dump Time | 1.1 s |
| Relief Valve Setting | 3,771 psi |
| Pump Type | axial piston |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 120 in |
| Wheelbase | 109 in |
| Width Over Tires | 88 in |
| Reach at Max Lift and Dump | 41 in |
| Length with Bucket on Ground | 258 in |
| Hinge Pin - Max Height | 149 in |
Transmission
| Max Speed - Forward | 25.5 mph |
|---|---|
| Max Speed - Reverse | 25.5 mph |
| Transmission Type | hydrostatic transmission. Volvo powershift |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.60 yd³ |
|---|---|
| Dump Clearance at Max Raise | 113 in |
| Breakout Force | 15,692 lb |
| Bucket Width | 91 in |
