Volvo
Case
21D
Wheel Loader
43 specifications
Volvo
LM 218
- Operating Weight
- 13,007 lb
- Bucket Capacity - heaped
- 2.80 yd³
- Gross Power
- 60.0 hp
- Net Power
- 56.0 hp
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 13,007 lb |
|---|---|
| Tire Size | front 14-30/10 rear 9-20/10 |
| Static Tipping Weight | 6,000 lb |
| Turning Radius | 198 in |
Engine
| Gross Power | 60.0 hp |
|---|---|
| Net Power | 56.0 hp |
Hydraulic System
| Pump Flow Capacity | 34.4 gal/min |
|---|---|
| Relief Valve Setting | 1,070 psi |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 101 in |
| Wheelbase | 95 in |
| Length with Bucket on Ground | 200 in |
Transmission
| Max Speed - Forward | 16.2 mph |
|---|---|
| Max Speed - Reverse | 12.5 mph |
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 5 |
Bucket
| Bucket Capacity - heaped | 2.80 yd³ |
|---|---|
| Bucket Capacity - struck | 0.80 yd³ |
| Dump Clearance at Max Raise | 122 in |
