Wacker Neuson
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 10,472 lb |
|---|---|
| Fuel Capacity | 22.1 gal |
| Hydraulic System Fluid Capacity | 52.8 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 77 A |
| Payload | 4,740 lb |
Engine
| Engine Model | TCD 2.9 |
|---|---|
| Displacement | 177 in³ |
| Gross Power | 73.7 hp |
| Engine Make | Deutz |
Hydraulic System
| Relief Valve Setting | 3,046 psi |
|---|
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 98 in |
| Wheelbase | 80 in |
| Width Over Tires | 71 in |
| Reach at Max Lift and Dump | 25 in |
| Length with Bucket on Ground | 209 in |
| Hinge Pin - Max Height | 130 in |
Transmission
| Max Speed - Forward | 20.0 mph |
|---|---|
| Transmission Type | Continuously variable hydrostatic axial-piston gearbox |
Bucket
| Bucket Capacity - heaped | 1.10 yd³ |
|---|---|
| Breakout Force | 9,172 lb |
| Tipping load Standard bucket | 8,047 lb |
General Specifications
| Operating Weight | 10,472 (4,750) — Starting 2022 Model Year |
|---|---|
| Bucket Capacity | 1.11 (.84) — Starting 2021 Model Year |
| Engine type | Deutz TCD 2.9 Tier 4 Final — Starting 2021 Model Year |
| Engine Power | 74 (55) — Starting 2019 Model Year |
| Max Dump Height | 8.4 (2.56) — Starting 2022 Model Year |
