Wacker Neuson
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 9,921 lb |
|---|---|
| Fuel Capacity | 15.6 gal |
| Tire Size | 12.5 - 20 |
| Hydraulic System Fluid Capacity | 13.3 gal |
| Static Tipping Weight | 7,055 lb |
| Operating Voltage | 12 V |
| Turning Radius | 137 in |
| Rear Axle Oscillation | 22 ° |
| Alternator Supplied Amperage | 95 A |
Engine
| Displacement | 221 in³ |
|---|---|
| Gross Power | 60.3 hp |
| Number of Cylinders | 4 |
| Engine Make | Deutz |
Hydraulic System
| Pump Flow Capacity | 19.6 gal/min |
|---|---|
| Raise Time | 5.5 s |
| Lower Time | 3.7 s |
| Dump Time | 1.5 s |
| Relief Valve Setting | 3,046 psi |
| Pump Type | Gear pump |
Dimensions
| Height - Top of Cab | 100 in |
|---|---|
| Wheelbase | 76 in |
| Width Over Tires | 69 in |
| Length with Bucket on Ground | 199 in |
| Hinge Pin - Max Height | 128 in |
Transmission
| Max Speed - Forward | 12.4 mph |
|---|---|
| Transmission Type | Continuously variable hydrostatic axial-piston gearbox |
Bucket
| Bucket Capacity - heaped | 1.10 yd³ |
|---|---|
| Dump Clearance at Max Raise | 100 in |
| Breakout Force | 7,868 lb |
