Wacker Neuson
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 10,659 lb |
|---|---|
| Fuel Capacity | 23.8 gal |
| Tire Size | 405/70-18 EM |
| Hydraulic System Fluid Capacity | 21.2 gal |
| Static Tipping Weight | 6,870 lb |
| Turning Radius | 155 in |
| Rear Axle Oscillation | 24 ° |
Engine
| Engine Model | BF4M 2011 |
|---|---|
| Gross Power | 75.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 17.0 gal/min |
|---|---|
| Relief Valve Setting | 3,046 psi |
| Pump Type | Gear pump |
Dimensions
| Height - Top of Cab | 103 in |
|---|---|
| Wheelbase | 79 in |
| Width Over Tires | 73 in |
| Length with Bucket on Ground | 214 in |
| Hinge Pin - Max Height | 132 in |
Transmission
| Max Speed - Forward | 12.4 mph |
|---|---|
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
Bucket
| Bucket Capacity - heaped | 0.99 yd³ |
|---|---|
| Dump Clearance at Max Raise | 102 in |
| Breakout Force | 7,713 lb |
