Wacker Neuson
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Max Speed | 12.5 mph |
|---|---|
| Tire Size | 405/70-18 EM ET 0 |
| Operating Voltage | 12 V |
Engine
| Engine Model | TCD 2.9 L4 |
|---|---|
| Displacement | 177 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 75.0 hp |
| Number of Cylinders | 4 |
| Engine Make | Deutz |
| Alternator | 95 A |
Weights
| Operating Weight | 11,243 lb |
|---|---|
| Breakout force maximum | 9,538 lb-ft |
| Lifting force maximum | 6,756 lb |
Hydraulic System
| Pump Flow Capacity | 15.0 gal/min |
|---|---|
| Relief Valve Pressure | 6,454 psi |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 103 in |
| Wheelbase | 79 in |
| Overall Length | 217 in |
| Width Over Tires | 74 in |
| Length with Bucket on Ground | 183 in |
| Turning Radius | 61 in |
| Track Width | 54 in |
Fluid Capacities
| Fuel Tank | 21.7 gal |
|---|---|
| Hydraulic oil tank | 17.5 gal |
Bucket
| Bucket Capacity - heaped | 0.99 yd³ |
|---|---|
| Dumping angle, top | 39 ° |
General Specifications
| Operating Weight | 11,244 (5,100) — Starting 2019 Model Year |
|---|---|
| Operating Weight lbs (kg) | 11,244 (5,100) — Starting 2025 Model Year |
| Bucket Capacity | 1.10 (.76) — Starting 2024 Model Year |
| Bucket Capacity cu. yd. (cu m) | 1.10 (.76) — Starting 2025 Model Year |
| Engine type | Deutz TCD 2.9 L4 — Starting 2024 Model Year |
| Engine Power | 74 (55) — Starting 2019 Model Year |
| Max Dump Height | 8.3 (2.51) — Starting 2019 Model Year |
| Max Dump Height ft.( m) | 8.3 (2.51) — Starting 2025 Model Year |
| OperatingWeight lbs. (kg) | 11,244 (5,100) — Starting 2026 Model Year |
| Engine Power Gross hp (kW) | 74 (55) — Starting 2025 Model Year |
