Zoomlion

ZE310

Excavator

Operating Weight
67,462 lb
Max Digging Depth
292 in
Net Power
237.4 hp
All excavators
Zoomlion ZE310 Excavator
1 / 5
Image 1 of 5
Image: product.cmsou.com

Specifications

24 data points

Operating Specifications

Operating Specifications specifications
Operating Weight67,462 lb
Fuel Capacity124.7 gal
Hydraulic System Fluid Capacity51.6 gal
Engine Oil Capacity6.3 gal
Cooling System Fluid Capacity8.0 gal
Swing Drive Fluid Capacity3.0 gal

Engine

Engine specifications
Engine Model6CTA8.3-C240
Displacement32,221 in³
Power Measured @2,000 rpm
Net Power237.4 hp
Torque Measured @1,500 rpm
Max Torque816 lb-ft

Dimensions

Dimensions specifications
Height - Top of Cab121 in
Length of Track on Ground180 in
Tail Swing Radius125 in
Width to Outside of Tracks126 in

Undercarriage

Undercarriage specifications
Max Travel Speed3.7 mph
Shoe Size24 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth292 in
Max Reach Along Ground431 in
Max Loading Height283 in
Max Cutting Height402 in

Bucket

Bucket specifications
Reference Bucket Capacity1.80 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed10 rpm
